AS39029 QPL Crimp Signal, RF Coax, Databus, High-Speed, and other Glenair Signature Contacts
Electrical connector contacts used in multi-pin military standard and commercial equivalent connectors (MIL-DTL-38999, MIL-DTL-24308 and others) are controlled by the MIL-DTL-39029 specification (now SAE AS39029) which regulates materials, dimensions, plating thicknesses, electrical properties and other key parameters. Contact types include crimp, coaxial, thermocouple, and wire-wrap variants all exactingly manufactured to strict M39029 requirements. Mil-standard connectors are typically supplied with loose contacts in both pin and socket configurations for a broad range of wire gauges.
Glenair brings a new perspective to the supply of high-performance Mil-Spec and commercial electrical contacts: High Availability! Whether you need a standard duty socket contact for a MIL-DTL-28840 connector or a short-run of shielded Quadrax, we have you covered with products that are always in stock — with no dollar or quantity minimums. We also supply many special-purpose and custom contact designs including pneumatic, high-voltage DC, thermocouple, and more.
Reference
- AS39029 and Glenair Signature Power, Signal, RF, Fiber Optic, and Controlled-Impedance Contacts Datasheet
- How to Determine Wire Strip Length for Machined Contacts
SAE-AS39029 Crimp Contacts: Standard-Duty and Expanded-Performance Pin and Socket Crimp Contacts
Mil-Qualified and Glenair Commercial Pin and Socket Crimp Contacts
Glenair brings a new perspective to the supply of Mil-Spec crimp contacts: High Availability. Whether you need a standard duty socket for a MIL-DTL-28840 connector or an extended duty pin for MIL-DTL-38999 Series III we have got you covered with products that are always in stock — with no dollar or quantity minimums. In addition to the broadest selection and availability, Glenair also delivers outstanding interconnection compatibility. Glenair QPL SAE-AS39029 contacts are guaranteed to mate properly and perform at the upper limits of application and specification requirements.
Reference
850-318
M39029/121
High-Density, Expanded-Performance Electrical Socket Contact
Crimp Socket Contact for High Vibration, High Temperature in MIL-DTL-38999 Series III Connectors
850-319
M39029/122
High-Density, Expanded-Performance Electrical Pin Contact
Crimp Pin Contact for High Vibration, High Temperature in MIL-DTL-38999 Series III Connectors
850-001
M39029/56
Standard Duty Electrical Socket Contact
Standard Socket Crimp Contact for MIL-DTL-38999 Series I, III and IV Connectors
850-003
M39029/57
Standard Duty Electrical Socket Contact
Standard Socket Crimp Contact for MIL-DTL-38999 Series II Connectors
850-002
M39029/58
Standard Duty Electrical Pin Contact
Standard Pin Crimp Contact for MIL-DTL-38999 Series I, II, III and IV Connectors
850-021
M39029/63
Standard Duty Electrical Socket Contact
Standard Socket Crimp Contact for MIL-DTL-24308
850-004
M39029/83
Standard Duty Electrical Pin Contact
Standard Pin Crimp Contact for MIL-DTL-28840 Connectors
850-005
M39029/84
Standard Duty Electrical Socket Contact
Standard Socket Crimp Contact for MIL-DTL-28840 Connectors
850-006
M39029/106
Extended Duty Electrical Socket Contact
Extended Duty Socket Crimp Contact for MIL-DTL-38999 Series I, III and IV Connectors
850-007
M39029/107
Extended Duty Electrical Pin Contact
Extended Duty Pin Crimp Contact for MIL-DTL-38999 Series I, III and IV Connectors
8577-0001
Jumper Wire M22759 with M39029/56 and 58 Contacts
8577-0001M = MIL-SPEC M22759
8577-0001G: Made IAW M22759 (GS22759)
PC-Tail Contacts, Pin and Socket for MIL-DTL-38999
857-027
M39029/58 Type
8 Gauge Pin Contact with PC Tails
For use in special MIL-DTL-38999 Series III rear release contact retention systems using #8 power contacts.
- 857-027-08-1
- 857-027-08-2
- 857-027-08-3
857-028
M39029/56 Type
8 Gauge Socket Contact with PC Tails
For use in special MIL-DTL-38999 Series III rear release contact retention systems using #8 power contacts.
- 857-028-08-1
- 857-028-08-2
- 857-028-08-3
Solder Cup Contacts, Pin and Socket for MIL-DTL-38999
850-015
M39029/56 Type
Socket Contact with Solder Cup
for D38999 Series I, III and IV Connectors
- 850-015-22
- 850-015-2
- 850-015-16
- 850-015-12
- 850-015-10
850-016
M39029/58 Type
Pin Contact with Solder Cup
for D38999 Series I, III and IV Connectors
- 850-016-22
- 850-016-20
- 850-016-16
- 850-016-12
- 850-016-10
850-017
M39029/58 Type
Pin Contact with Extended Rear Solder Cup
for D38999 Series I, III and IV Connectors
- 850-017-22
- 850-017-20
- 850-017-16
- 850-017-12
Size #8 Power Contacts, Pin and Socket for MIL-DTL-38999
Contacts for MIL-DTL-28840 Shipboard Electrical Connectors: NAVSEA-Qualified QPL and Glenair Signature
RF, Microwave, and mmWave Contacts for SuperNine RF, Series 806 RF, Series 795 RF Connectors
Glenair manufactures an extensive range of high-frequency RF contacts for drop-in use in Glenair signature series connectors including Series 23 SuperNine RF, Series 806 RF, and Series 795 RF high-density rectangular. The use of aerospace-grade sealed and shielded multiport connectors of this type is advantageous both as a mechanism to ruggedize the I/O interface as well as for size- and space-savings. All designs are optimized for packaging in Glenair signature series connectors and fall into three contact cavity sizes: #8, #12, and #16. These are 50 and 75 Ohm contacts in BMB, SMPM, and SMPS formats. Selected contacts utilize millimeter-wave spring-loaded architecture to achieve frequencies up to 65 GHz. All are designed for direct attachment of coaxial cables and snap-in insertion to multi-cavity connectors.
Catalog: RF, Microwave, and mmWave Interconnects and Coax Cable Assemblies for Mission-Critical Aerospace Applications.
Turnkey Coaxial Interconnect Solutions: Integrated RF Interconnect Assemblies built from Aerospace-Grade Connectors, Contacts, Adapters, and Glenair BluMark RF™ Coax Cables.
- View eBook
- Download or View PDF (Single pages, print friendly)
SuperNine RF
852-133 Pin
852-314 Pin
852-134 Socket
852-315 Socket
65 GHz Size #16 SMPS
50 Ohm RF Contacts
for D38999 RF
SuperNine RF
852-157 Pin
852-158 Socket
G-LinkRF (GLink RF)
18 GHz Size #8
BMB-to-SMA Adapter
for D38999 RF
SAE-AS39029 Qualified and Commercial-Grade Shielded Coax Crimp Pin and Socket Contacts
For Use In MIL-DTL-38999, Series 23 SuperNine, Series 80 Mighty Mouse, and Series 79 Micro-Crimp Connectors
AS39029 Qualified Coaxial Size #8, Size #12, and Size #16 contacts are designed for aerospace and defense equipment subjected to high-vibration and temperature extremes with supported frequencies from DC – 3 GHz.
RF, Microwave, and Shielded Contacts
For MIL-DTL-38999, Series 23 SuperNine®, Series 80 Mighty Mouse, and Series 79 Micro-Crimp® Connectors
Series 85
SAE-AS39029 RF Coax Contacts
Size #8 AS39029 Coaxial Contacts
Size #8 AS39029 Coaxial Pin and Socket Crimp Contacts for RG-180
DC – 700 MHz
For D38999 Series I, III, and IV, SuperNine, and Mighty Mouse connectors. AS39029 qualified.
Size #12 AS39029 Coaxial Contacts
Size #12 AS39029 Coaxial Pin and Socket Crimp Contacts
for RG-174, RG-179, RG-180 and RG-316 Cable
DC – 3 GHz
For D38999 Series I, II, III, and IV, SuperNine, Series 79 Micro-Crimp, and Mighty Mouse connectors. AS39029 qualified.
Size #16 AS39029 Coaxial Contacts
Size #16 AS39029 Coaxial Pin and Socket Crimp Contacts
for RG-174, RG-179, RG-180, and RG-316 Cable
DC – 500 MHz
For D38999 Series I, II, III, and IV, SuperNine, Series 79 Micro-Crimp, and Mighty Mouse connectors. AS39029 qualified.
Glenair 50 and 75 Ohm Low-Loss Matched-Impedance Coaxial Contacts
Size #8 50 Ohm Matched-Impedance Contacts
Size #8 50 Ohm Matched-Impedance Pin and Socket Contacts
for RG-316 Single- and Double-Shield or M17/220-0001 Cable
DC – 6 GHz
For D38999, SuperNine, and Mighty Mouse connectors
Size #12 50 Ohm Matched-Impedance Contacts
Size #12 50 Ohm Matched-Impedance Contacts
for RG-178, RG-316, and RG-405 flex cable
DC – 3 GHz
For D38999 Series I, II, III, and IV, SuperNine, Series 79 Micro-Crimp and Mighty Mouse connectors
Size #8 75 Ohm Matched-Impedance Contacts
Size #8 75 Ohm Matched-Impedance Pin and Socket Contacts
for RG-179, RS170, SMPTE 292M, SMPTE 424M and other video cables
DC – 4 GHz
For D38999 Series I, III, and IV, SuperNine, and Mighty Mouse connectors
Size #12 75 Ohm Matched-Impedance Contacts
Size #12 75 Ohm Matched-Impedance Contacts
for RS170, SMPTE 292M and other video cables
DC – 3 GHz
For D38999 Series I, II, III, and IV, SuperNine, Series 79 Micro-Crimp and Mighty Mouse connectors
M39029 Type Twinax and Quadrax Contacts for Data Bus and 100BASE-T Ethernet Applications
Size #8 77 Ohm Concentric Twinax Contacts
Size #8 77 Ohm Concentric Twinax Contacts
for 77 Ohm M17/176-00002 databus cable
10 MHz
IAW M39029/113 and /114. For D38999, SuperNine and Mighty Mouse connectors.
Size #8 100 Ohm Concentric Twinax Contacts
Size #8 100 Ohm Concentric Twinax Contacts
for 24 AWG 100 ohm TE/Raychem 0024A0024 and Gore GSC-03-81416-00 cables
1 MHz
For D38999 Series I, III, and IV, SuperNine, and Mighty Mouse connectors.
Size #12 77 Ohm Concentric Twinax Contacts
Size #12 77 Ohm Concentric Twinax Contacts
for 77 ohm shielded twisted pair data cable
10 MHz
IAW JN1104, DSCC 02003 and DSCC 02004. For D38999 Series I, III, and IV connectors.
Size #8 Differential Twinax Contacts
Size #8 Differential Twinax Contacts
for 68, 75, 77 and 100 ohm and M17/176-00002 databus cable
DC – 3 GHz
For Mighty Mouse and Glenair 233-217 D38999 Series III SuperNine connectors with keyed #8 cavities.
Size #8 100 Ohm and 150 Ohm Quadrax Contacts
Size #8 100 Ohm and 150 Ohm Quadrax Contacts
for Aerospace-Grade Quad Cable
100 ohm Ethernet / 150 ohm Fibre Channel
For Mighty Mouse and Glenair 233-217 D38999 Series III type SuperNine connectors with keyed #8 inserts.
8589-0001
Quadrax Cable Assemblies
Aerospace-grade cable. 100% tested. Available with pin/pin, pin/socket, socket/socket, pin/RJ45 and socket/RJ45 configurations.
For Glenair Series 23, 28, 792, 806, and ARINC 600 connectors.
Thermocouple Contacts for MIL-DTL-38999, MIL-DTL-24308, and Series 28 HiPer-D Connectors
850-329
Thermocouple Socket Contact with Crown Ring
for D38999 and SuperNine Connectors
500 mating cycles
IAW AS39029/121
859-172
Thermocouple Wire Barrel Reducer Bushing
To reduce the barrel size of M39029/87, M39029/88 and M39029/89 thermocouple contacts to accommodate smaller wire size.
850-023
M39029/87 Type
Thermocouple Pin Contact
for D38999 Series I, II, III and IV and M24308 Connectors
850-111
M39029/63 Type
Thermocouple Socket Contact, Size #20
for MIL-DTL-24308 and Series 28 HiPer-D Connectors
850-112
M39029/64 Type
Thermocouple Pin Contact, Size #20
for MIL-DTL-24308 and Series 28 HiPer-D Connectors
857-451
Thermocouple Jumper
857-451-01 Thermocouple Cable, Twisted Pair, P/N: 968-039
857-451-02 Extension Thermocouple Cable, Twisted Pair, P/N: 968-026
MIL-DTL-38999 Series III
8577-0001
Jumper Wire M22759 with M39029/56 and 58 Contacts
8577-0001M MIL-SPEC M22759
8577-0001G Made IAW M22759 (GS22759)
Pneumatic Contacts for D38999 Series I, II, III, and IV and Mighty Mouse Connectors
Bushings, Adapters, and Dummy Contact Sealing Plugs
M39029/112
GS39029/112
Milspec qualified Wire Barrel Reducer Bushing
for use with Larger Gauges
Crimp Contacts M39029/45 and /44
Dummy Contact Sealing Plugs (DCSP)
For D38999, SuperNine, Mighty Mouse, Series 806, and Series 79 Connectors
Weight/Cost-Saving
For reliable sealing of unused contact cavities
kV Seal™ High-Voltage Contact Assemblies
13.5 kVDC–22 kVDC High-Voltage, Low Amperage Insertable / Removable Contact Assemblies for High-Voltage DC Circuit Applications
Glenair kV Seal™ contact assemblies are used in applications such as traveling-wave tube RF amplifier devices, directional radar, missile seekers, fire control systems, and other electronic devices that utilize extremely high-voltage circuits in their operation. High-voltage DC is used for the excitation and activation of certain electronic elements within these systems.
- Seals interface air gap
- Air-excluding interface and overmolded wire strain relief increase breakdown strength at higher altitudes
- Obstructs interface creep path, increasing breakdown strength against surface tracking
- Modular design integrates into multiple connector packages
- Scales for various operating voltages
kV Seal pre-wired single- or double-ended assemblies are designed for drop-in use in Glenair signature SuperNine connectors (D38999 Series I, II, III, and IV type), Mighty Mouse, and Series 79 Micro Crimp rectangular connectors. Size #12 kV Seal contacts may be paired with #22 or #24 AWG wire for applications requiring 13.5 kVDC operating voltage. kV Seal Plus designs provide 15 kVDC voltage performance. Size #8 kV Seal high-voltage contacts utilize #16 AWG wire for 22 kVDC operating voltage. These insertable / removable assemblies are compatible with mil-standard 1560 contact arrangements incorporating non-keyed size #12 and size #8 contacts.
Reference
kV Seal™ High-Voltage Contact Assemblies
13.5 kVDC–22 kVDC High-Voltage, Low Amperage Insertable / Removable Contact Assemblies for High-Voltage DC Circuit Applications
GHV-001
kV Seal Size #12 Contacts
13.5 kV contacts for SuperNine and D38999 Series I, III, and IV connectors
GHV-002
kV Seal Plus Size #12 Contacts
15 kV contacts for SuperNine and D38999 Series I, III, and IV connectors
GHV-003
kV Seal Size #12 Contacts
13.5 kV contacts for Mighty Mouse, Series 79, and D38999 Series II connectors
GHV-004
kV Seal Size #8 Contacts
22 kV contacts for Size #8 cavities in SuperNine, Mighty Mouse, and Series 79 rectangular connectors
Series-Specific Contacts for Glenair Signature Circular Connectors
Series 806 Mil-Aero D38999 Micro Miniature
Signal, Power, High-Speed, RF Coax, Thermocouple and more
SuperNine D38999 Series III
QPL and extended-durability crimp contacts: signal, power, coax, and more
Contacts for PowerPlay High-Power Connectors: SuperNine Series I and III PowerPlay, Series 806 Mil-Aero PowerPlay, Series 971 Micro-Crimp PowerPlay
850-202-20 Standard
850-346-20 Extended-Length
#20 Pin Contacts
for Micro-Crimp PowerPlay and SuperNine I and III PowerPlay
850-347-20
AS39029/56 Type Crimp Socket Contact
for Micro-Crimp PowerPlay and SuperNine I and III PowerPlay
Contacts for Series 970 PowerTrip High-Performance Power Connectors
Contacts for Series 790, 791, and 793 Micro-Crimp Aerospace Rectangular Connectors
High-Speed, Coax, Twinax, Quadrax, and Octaxial Contacts for Series 792 Micro-Crimp Connectors
Contacts for HiPer-D M24308 Connectors: Signal, Power, Coax
Optoelectronic Transmitter and Receiver Contacts
Size #8 Cavity Insert Optoelectronic Transmitter and Receiver Contacts
1.25 mm ARINC 801, 2.5 mm ELIO, and 1.25 mm LuxCis Integrated Solutions
for Size 8 Cavity Inserts
