Series 80 Mighty Mouse Hermetic Connectors

Series 80 Mighty Mouse Hermetic Connectors

The Series 80 Mighty Mouse Connector is designed for high-reliability commercial and aerospace/defense interconnect applications that require both robust environmental/EMI performance and reduced size and weight. The Series 80 Mighty Mouse Connector offers comparable performance to MIL-DTL-38999 Series interconnects with up to 71% weight and 52% size savings for similar contact layouts. The six versions of the product offer a variety of styles and features to suit just about any application.

Mighty Mouse Hermetic Reference

Mighty Mouse General Information and Reference

Series 80 Connectors for Space Flight

The small size and reduced weight of the Series 80 connector make it an excellent choice for space instrumentation. Series 80 connectors are available with special screening and outgassing for satellites and space vehicles. This section explains NASA guidelines for connector selection, screening, and outgassing. This section also explains how to order connectors screened to meet NASA EEE-INST-002.


Mighty Mouse Glass-to-Metal Hermetic Connectors

Series 800 PCB Hermetic Receptacle 800-013

800-013
Series 800 PCB Hermetic Receptacle

Miniaturize glass-sealed hermetic receptacle connectors are available with solder cup or PC tail contacts. Jam-nut, square flange, or solder mount versions available. Contacts are gold plated iron alloy. 100% tested to meet 1 x 10-7 cc/sec helium leakage. Backpotted and parylene compatible.

Hermetic PC Tail or Solder Cup Receptacle 801-012

801-012
Hermetic PC Tail or Solder Cup Receptacle

Stainless steel, glass-sealed connectors are available with solder cup or PC tail contacts. Choose jam-nut, square flange or solder mount versions. Contacts are gold plated iron alloy. Integral .025 (0.64) standoffs for board washout 100% tested to less than 1 x 10-7 cc/second helium leak rate.

Hermetic Receptacle with Coax Pin Contacts and Crimp Cable Adapter 801-059

801-059
Hermetic Receptacle with Coax Pin Contacts and Crimp Cable Adapter

Connector comes with cable adapters for termination of cable. Stainless steel, glass-sealed connectors with size 16 (up to 700 MHz) and size 12 (up to 3 GHz) coax contacts. Jam-nut, square flange or solder mount shell styles with solder washout standoffs. Contacts are gold plated nickel alloy. 100% tested to 1 x 10-7 cc/second helium leak rate.

Series 802 Hermetic Receptacle with Accessory Threads, PC Tails/Solder Cup 802-013

802-013
Series 802 Hermetic Receptacle with Accessory Threads, PC Tails/Solder Cup

Stainless steel, glass-to-metal hermetic PCB connectors with PC tail or solder cup contacts. Select front or rear panel mount jam-nut, front panel mount square flange or weld mount shell styles. Contacts are gold plated iron alloy. 100% tested and rated than 1 x 10-7 ccHe/sec leak rate. Open face pressure rating 1000 PSI.

Series 802 Hermetic Receptacles with Coax Contacts 802-040

802-040
Series 802 Hermetic Receptacles with Coax Contacts

These stainless steel, glass-sealed connectors are available with size 12 or 16 coax contacts only. Choose front or rear panel mount jam-nut or box mount connector versions. Contacts are gold plated iron alloy. 100% tested and rated to 1 x 10-7 ccHe/sec leak rate. Open face pressure rating 1000 PSI.

Series 803 Hermetic Receptacles with Solder Cups or PC Tails 803-006

803-006
Series 803 Hermetic Receptacles with Solder Cups or PC Tails

Hermetic receptacle with stainless steel shells are glass-sealed and available with solder cup or PC tail contacts. Choose jam-nut or flange mount versions. Contacts are gold plated iron alloy. 100% tested to meet 1 x 10-7 cc/sec helium leakage. Open face pressure rating 1000 PSI.

Hermetic Receptacles with PC Tails or Solder Cups 804-006

804-006
Hermetic Receptacles with PC Tails or Solder Cups

Miniaturized glass-to-metal seal hermetic receptacle for sealed box or instrument panel applications. These stainless steel connectors are available with solder cup or PC tail contacts. 100% tested to 1 x 10-7 cc/second helium leak rate. Open face pressure rating 1000 PSI.

Glass-Sealed Hermetic Board Mount Receptacle 805-006

805-006
Glass-Sealed Hermetic Board Mount Receptacle

Glass-to-metal seal PCB receptacle with .025 (0.64) integral standoff for board washout. Available in square flange, solder mount, weld mount, and jam-nut shell styles. 100% tested to meet 1 x 10-7 ccHe/sec @ 1 atm helium leak rate. Contacts are non-removable. Connector is backpotted and parylene compatible.

Glass-Sealed Hermetic Receptacle with PC Tail Coax Contacts 805-130

805-130
Glass-Sealed Hermetic Receptacle with PC Tail Coax Contacts

Glass-to-metal seal hermetic connector features PC tail Coax contacts for attachment to flexible or rigid board. Integral .025 (.64) standoff for board washout. Available in square flange, solder mount, and jam-nut shell styles. 100% tested to meet 1 x 10-7 ccHe/sec @ 1 atm helium leak rate. Backpotted and parylene compatible.

Jam-Nut Hermetic Bulkhead Feedthrough Connector 805-127

805-127
Jam-Nut Hermetic Bulkhead Feedthrough Connector

Hermetic glass-to-metal feedthru connectors offer a separable connection on both sides of the mounting panel. Innovative encapsulant allows for aluminum shells and gold plated copper alloy contact for improved performance and weight savings. 100% tested to meet 1 x 10-7 ccHe/sec @ 1 atm helium leak rate. Backpotted and parylene compatible.

Series 802 Hermetic Receptacle with Crimp Removable Termination and Integral Banding Porch 802-056

802-056
Series 802 Hermetic Receptacle with Crimp Removable Termination and Integral Banding Porch

Stainless steel, glass-to-metal hermetic connectors are available with crimp removable termination and integral banding porch. Choose jam-nut or square flange versions. Contacts are gold plated iron alloy. 100% tested and rated to 1 x 10-7 ccHe/sec leak rate. Hydrostatic pressure rating of 3500 PSI when fully mated and properly molded.

Mighty Mouse CODE RED Lightweight Hermetic Connectors

CODE RED Lightweight Hermetic Receptacle, Solder Cup, or PC Tail 801-140

801-140
CODE RED Lightweight Hermetic Receptacle, Solder Cup, or PC Tail

Series 801 Lightweight Hermetic Receptacles
Feature an advanced hermetic encapsulant seal for a leak rate performance of 1 x 10-7 ccHe/second. Encapsulant seal allows for the use of copper alloy / gold plated contacts for improved performance over nickel-iron contacts typically found in glass-to-metal sealed connectors. Modified double-start stub ACME mating thread for improved protection against cross-mating and thread damage. Three shell styles — square flange, jam nut and weld mount, available.Solder cup or PC tail contacts for attachment to flex or rigid circuit boards.

Mighty Mouse Accessories

Flange Gaskets for Series 800, 801, 802, 803, and 805 Mighty Mouse Flange Receptacles 809-108

809-108
Flange Gaskets for Series 800, 801, 802, 803, and 805 Mighty Mouse Flange Receptacles

  • Flange Gaskets for Series 800 Mighty Mouse Square Flange Receptacles
    These flange gaskets provide sealing between square flange receptacles and the mounting panel. Choose fluorosilicone, Viton®, or conductive fluorosilicone material (Chomerics 1298 silver-filled). Gaskets are .032" (0.8) thick.
  • Flange Gaskets for Series 801 Mighty Mouse Square Flange Receptacles
    These flange gaskets provide sealing between square flange receptacles and the mounting panel. Choose fluorosilicone, Viton®, or conductive fluorosilicone material (Chomerics 1298 silver-filled). Gaskets are .032" (0.8) thick.
  • Flange Gaskets for Series 802 Mighty Mouse Square Flange Receptacles
    These flange gaskets provide sealing between square flange receptacles and the mounting panel. Choose fluorosilicone, Viton®, or neoprene material. Gaskets are .032" (0.8) thick.
  • Flange Gaskets for Series 803 Mighty Mouse Receptacles
    These flange gaskets provide sealing between elliptical flange receptacles and the mounting panel. Choose fluorosilicone, Viton®, or conductive fluorosilicone material (Chomerics 1298 silver-filled). Gaskets are .032" (0.8) thick.
  • Flange Gaskets for Series 805 Mighty Mouse Square Flange Receptacles
    These flange gaskets provide sealing between square flange receptacles and the mounting panel. Choose fluorosilicone, Viton®, or conductive fluorosilicone material (Chomerics 1298 silver-filled). Gaskets are .032" (0.8) thick.
Mounting Flange with Standard or Metric Threads for Series 800, 801, 802, and 805 Connectors

Mounting Flange with Standard or Metric Threads for Series 800, 801, 802, and 805 Connectors

  • 809-199 = Mounting Flange with standard threads
  • 809-303 = Mounting Flange with metric threads
