Underwater / Subsea Connectors and PBOF Assemblies for High-Pressure Mission-Critical Marine Applications

Underwater connectors, custom high-pressure cable, Pressure Balanced Oil Filled (PBOF) assemblies, and connector terminations. Depth rated to 10,000 psi (700 BAR) for naval and defense, deep-sea oil and gas industry, pipeline inspection (PIG), and oceanographic applications. Also, downhole, high-pressure and above-deck shipboard interconnect solutions. Underwater dry-mate fiber optic and high-speed electric solutions with 10KPSI pressure ratings.

Underwater / Subsea Connectors and PBOF Assemblies for High-Pressure Mission-Critical Marine Applications

Glenair excels in the design and manufacture of high-pressure, underwater connectors and interconnect cable assemblies for electrical and fiber optic applications. Our swivel-attachment equipped Pressure Balanced Oil Filled cable assemblies (PBOF) are revolutionary designs that solve a myriad of problems such as kinked and twisted hoses, leaky fittings, corroded hose clamps, and general poor performance that characterize existing industry PBOF solutions. Glenair manufactures several complete lines of oil filled (PBOF) and depth-rated cable assemblies for deep-sea applications. Our Engineering team is comprised of industry experts with extensive knowledge and experience in the subsea industry including submarines, ROV/AUV, seafloor operations, geophysical and pipeline inspection projects. In addition to high-pressure underwater solutions, Glenair's offerings extend to topside applications such as ATEX certified interconnects for explosion (EX) rated zones, miniaturized connector for pipeline inspection, navy QPL optical and electrical interconnects, LSZH cabling and conduit solutions and more. Connectors are 100% inspected and tested in our state-of-the-art hyrdrostatic test lab via a formalized qualification test plan model that includes combined testing across pressure, durability, shock, salt spray corrosion as well as other stress factors.

Glenair Signature Series Deep-Water Down-Hole Top-Side Shallow-Water
SeaKing 700
SeaKing Junior
Micro-PSI
Well-Master 260°
SeaKing Fiber Optic
SuperG55
Underwater Connectors

Underwater Connectors

Topside and Subsea Connectors / PBOF Assemblies for High-Pressure Oil & Gas Industry Interconnect Applications
  • eBook
  • PDF (Two-page spreads)
  • PDF (Single pages, print friendly)
Deep Dive: Glenair Subsea Interconnect Technologies

Deep Dive: Glenair Subsea Interconnect Technologies

Glenair has developed a superior PBOF technology design that allows for faster, easier assembly and ease-of-repair in the field, and the utilization of both straight and sweeping, non-constricting 45° and 90° elbows. These improvements and a host of others are now available in Glenair SeaKing high-pressure connectors and coming soon in our revolutionary SuperG55 series. The SubSea/Marine Team at Glenair invites you to enjoy the rest of this special edition of QwikConnect and to contact the factory for applications and design-in support.
  • eBook
  • PDF (Two-page spreads)
  • PDF (Single pages, print friendly)

Slideshow Presentation

Underwater / Subsea Connectors and PBOF Assemblies for Mission-Critical Marine Applications

Underwater / Subsea Connectors and PBOF Assemblies for Mission-Critical Marine Applications

Underwater connectors, custom high-pressure cable, Pressure Balanced Oil Filled (PBOF) assemblies, and connector terminations. Depth rated to 10,000 psi (700 BAR) for naval and defense, deep-sea oil and gas industry and oceanographic applications. Also, downhole, high-pressure and above-deck shipboard interconnect solutions. Underwater dry-mate fiber optic and high-speed electric solutions with 10KPSI pressure ratings.
  • PDF (Two-page spreads)
Deep-Water Subsea, High-Pressure 10K PSI / 700 Bar / 7000m Connectors Deep-Water

Deep-Water Subsea, High-Pressure 10K PSI / 700 Bar / 7000m Connectors

Next-generation high-speed, signal, and power connectors for mission critical underwater applications — from submarines and ROVs to seafloor oil and gas production platforms
  • SeaKing™ 700 10K PSI Open-Face High-Density Underwater Connectors and Cables
  • SeaKing Junior / Series 701 High-reliability, dry-mate, harsh-environment connectors and cables for intelligent inline inspection PIGs
  • SeaKing™ Fiber Optic 10K PSI Open-Face Pressure Rated Underwater Fiber Optic Connectors, Cables and Jumpers, Plus Ruggedized Transceivers and Media Converters
  • SeaKing™ Power 1—5kV Connectors for Deep Sea Oil & Gas Primary Power Junctions
  • SuperG55™ Dry-Mate 10K PSI Underwater Electrical Connectors
  • Innovative Pressure Balanced Oil Filled cable and hose assemblies
  • Economical Marine Molded Cable-to-Cable and Cable-to-Panel Interconnects
Down-Hole High-Temperature / High Pressure Connectors Down-Hole

Down-Hole High-Temperature / High Pressure Connectors

Small form-factor solutions tailored for harsh-environment geophysical downhole tooling applications — with high temperature tolerance and high pressure glass sealing
  • Well-Master® High Temperature Micro-D Connectors
  • Single- and Multi-pin Height Temperature/High Pressure (HTHP) Glass Sealed Penetrators and Feedthroughs
  • ThermaRex Cryogenic and High-Temperature Tolerant Connectors, Cables, and Conduit Systems
Top-Side or Shipboard Connectors Top-Side

Top-Side or Shipboard Connectors

Composite thermoplastic, marine bronze, and stainless steel interconnect wire system components for ruggedized salt spray and explosive zone applications
  • SeaCrow™ Rugged Marine Bronze Environmental Connectors
  • ITS-Ex ATEx-Qualified and Approved Explosive Zone Connectors
  • Corrosion-Resistant Composite Junction Boxes, Cable Bays, and Wire Protection Conduit
  • NAVSEA-Qualified Metal-Core Conduit Systems
  • MIL-DTL-28840 Navy Electrical Connectors
  • MIL-PRF-28876 Navy Fiber Optic Connectors
Shallow-Water Underwater Connectors Shallow-Water

Shallow-Water Underwater Connectors

Piston O-ring and hermetically sealed interconnect technologies with marine-grade stainless steel and Marine Bronze materials for power, signal, and high-speed applications in shallow water, pipeline inspection (PIG), and other underwater environments
  • Geo-Marine® 5000 PSI connectors and overmolded cables
  • AquaMouse™ 3500 PSI miniature Connectors and overmolded cables
  • Micro-PSI Microminiature high-pressure connectors and cables for Pipeline Inspection Applications
  • Turnkey Connectorized Flex/PCB Cable Assemblies
