Micro-D Hermetics for High-Density, Vibration- and Shock-Resistant Military Aerospace-Grade Applications

Glenair MIL-DTL-83513 type Micro-D hermetic connectors are ideal for high-pressure/low-leakage applications where size, weight, and vibration resistance are a critical concern. Sophisticated electronics enclosures, vacuum chambers, and cryogenic equipment all benefit from the airtight seal and moisture-resistant plating found on Glenair hermetic Micro-D connectors. Solder mount, weld mount, and rear panel O-ring shell styles are available to meet a variety of design requirements.

Hermetic Materials

Kovar® — an iron-nickel alloy — is used in both the shells and contacts, and provides a chemical bond with the glass insulator for maximum hermeticity. Shells are then plated with nickel after the glass insulator is fired, to enhance corrosion resistance. Contacts are plated with gold to ensure superior electrical conductivity. Hermetic receptacle connectors are offered with a minimum of 9 sockets, up to a maximum of 100 sockets — in two-, three-, and four-row solder cup and pigtail configurations. Fluorosilicone rubber interfacial seals and O-rings ensure positive sealing with plug connectors and panels. Gold-plated Kovar® socket contacts boast superior vibration resistance when used in conjunction with Glenair's innovative TwistPin contact system in the plug.

Same-Day Hermetic Connector Inventory

Because Glenair makes all its hermetic connectors in-house, including the machining of shells, molding of interfacial seals and firing of hermetic components, we can offer you outstanding availability on stock products and fast turnaround on special orders.

Micro-D Hermetic Connector Reference Information

Hermetic Connectors > MIL-DTL-83513

MIL-DTL-83513 Type Micro-D Hermetic Connectors, 177-140H and 177-704H Solder Mount Receptacles

177-140H and 177-704H
Solder Mount Receptacles

MIL-DTL-83513 Type Micro-D Hermetic Connectors

Solder-Cup, PC-Tail, and Pre-Wired Configurations

  • Solder-Mount
    177-140 hermetic Micro-D connectors featuring a matched glass-to-metal seal. These socket receptacles are designed for solder panel mounting.
  • Kovar® Shells and Contacts
    Complies with applicable MIL-DTL-83513 requirements and are 100% intermateable with standard connectors.
  • Choose 9 to 100 Contacts
    With gold-plated contacts and nickel-plated shells. These connectors feature integral female jackposts.
Glass-Sealed Hermetic Micro-D Socket Receptacle, Weld Mount, GLI-24042-1

GLI-24042-1
Glass-Sealed Hermetic Micro-D Socket Receptacle, Weld Mount

MIL-DTL-83513 Type Micro-D Hermetic Connectors

Solder-Cup and PC-Tail Termination
MIL-DTL-83513 Type Micro-D Hermetic Connectors, Rear Panel Mount with O-Ring, 177-705H and 177-706H

177-705H and 177-706H
Rear Panel Mount with O-Ring

MIL-DTL-83513 Type Micro-D Hermetic Connectors

Solder-Cup, PC-Tail, and Pre-Wired Configurations

  • Fluorosilicone O-Ring
    Eliminates the cost of soldering the connector to a bulkhead.
  • Kovar® Shells and Contacts
    Complies with applicable MIL-DTL-83513 requirements and are 100% intermateable with standard connectors.
  • Solder Cup, PC Tail or Pre-Wired / Fully Potted
    Suitable for #26 gage wire or smaller, solder cup versions feature gold-plated contacts. Choose PC tails for attachment to flex circuits or rigid boards. Solder cup versions are also available pre-wired and potted.
Panel Mount O-Ring Seal, Socket-Socket Mating Interfaces, Bulkhead Feed-Thru, 1770-3687

1770-3687
Panel Mount O-Ring Seal, Socket-Socket Mating Interfaces, Bulkhead Feed-Thru

MIL-DTL-83513 Type Micro-D Hermetic Bulkhead Feed-Thru

Socket-Socket Mating Interface

  • O-Ring Mounting
    Eliminates the cost of soldering the connector to a bulkhead.
  • Kovar® Shells and Contacts
    Complies with applicable MIL-DTL-83513 requirements and are 100% intermateable with standard connectors.
Panel-Mount O-Ring Seal, Pin-Socket Mating Interfaces, Bulkhead Feed-Thru, 1770-5588

1770-5588
Panel-Mount O-Ring Seal, Pin-Socket Mating Interfaces, Bulkhead Feed-Thru

MIL-DTL-83513 Type Micro-D Hermetic Bulkhead Feed-Thru

Pin-Socket Mating Interface

  • O-Ring Mounting
    Eliminates the cost of soldering the connector to a bulkhead.
  • Kovar® Shells and Contacts
    Complies with applicable MIL-DTL-83513 requirements and are 100% intermateable with standard connectors.
Front Panel Mount, Thru-Hole Flange Receptacle, PC Tail or Solder Cup Socket Contacts, 1770-5600

1770-5600
Front Panel Mount, Thru-Hole Flange Receptacle, PC Tail or Solder Cup Socket Contacts

MIL-DTL-83513 Type Micro-D Hermetic Connectors

  • Glass-to-Metal Seal, Front Mount
