Environmental Sealing and Rugged Design in a Lightweight, Push-Pull Package
Series 804
Ideal for breakaway connections, the Series 804 QDC connector features a goldplated stainless steel spring in the receptacle and a detent on the plug body for reliable mating retention. Used for headsets, radios, weapons, and other tactical applications, the QDC Mighty Mouse 804 meets IP67 immersion requirements in the mated condition. The gold-plated spring provides low shell-to-shell resistance for excellent EMI shielding. A fluorosilicone O-ring provides a watertight seal in the mated condition.
- Push-to-Mate, Pull-to-Unmate
- Gold-Plated Stainless Steel EMI Spring
- Crimp Rear-Release Contacts
- Integral Band Platform
- Available with Size #12, #16, #20, #20HD and #23 Contacts
- Environmentally Sealed
Datasheets
Reference
- Product Selection Guide
- Specifications, and Materials and Finishes
- Quick Disconnect, Connector Maximum Weight by Shell Size and Insert Arrangement
- Contact Layouts — Mating Face of Pin Insert Shown
- Panel Cutout Dimensions, Demate Force, and Polarization
