MIL-DTL-26482 Series I and II Type Hermetic Connectors

Fast and Reliable Mating

Glenair MIL-DTL-26482 Series I and II Bayonet-Lock Connectors are ideally suited for vacuum chambers and other military and commercial applications that utilize this general purpose medium density cylindrical connector and require helium leak test rates of less than 1x10^-7 cc/second. The bayonet mechanism provides fast and easy coupling, especially when the connector is situated in an awkward or hard to reach location. A wide range of available mounting styles–including both narrow and wide flange mounts–provide complete flexibility in interconnect system design. PCB and solder cup contacts allow easy integration and termination to I/O cabling and electronic sub-systems. Glenair MIL-DTL-26482 Type hermetics are interchangeable and intermateable with the wide range of industry-standard bayonet connectors designed around MIL-DTL-26482 and/or qualified to VG 95328, including ITT Cannon KPT.

MIL-DTL-26482 Type

• Insert Arrangements per MIL-DTL-1669
• Key/Keyway Positions
• Special Leak Rate Mod Codes

Glenair Hermetic Connector Products

• Special Leak Rate Mod Codes
• Space Grade Application Guide

Hermetic Connectors > Section D

	230-014 MIL-DTL-26482 Series I Type Hermetic Bayonet Coupling Solder Mount Receptacle MS3113 Type
	230-015 MIL-DTL-26482 Series I Type Hermetic Bayonet Coupling Jam Nut Receptacle MS3114 Type
	947-303 Narrow Flange Mount Bulkhead Feed-Thru MS3440 Type
	230-035 MIL-DTL-26482 Series I Type Hermetic Bayonet Coupling Narrow Flange Mount Receptacle MS3112 Type
	230-016 MIL-DTL-26482 Series II Type Hermetic Bayonet Coupling Narrow Flange Mount Receptacle MS3440 Type
	230-017 MIL-DTL-26482 Series II Type Hermetic Bayonet Coupling Wide Flange Mount Receptacle MS3442 Type
	230-018 MIL-DTL-26482 Series II Type Hermetic Bayonet Coupling Solder Flange Mount Receptacle MS3443 Type
	230-019 MIL-DTL-26482 Series II Type Hermetic Quick Release Bayonet Receptacle Single Hole Jam-Nut Mount MS3449 Type
	230-022 MIL-DTL-26482 Series II Type Hermetic Bayonet Coupling Jam Nut Mount Receptacle with Crimp Removable Contacts • MS3479 Type
	230-034 MIL-DTL-26482 Series II Type Hermetic Bayonet Coupling Jam-Nut Mount Receptacle MS3449 Type
	237-051 MIL-DTL-26482 Series II, MS3440 Type Hermetic Special Narrow Square Flange Mount Receptacle with Bayonet Coupling and Solder Cup Termination
	237-133 MIL-DTL-26482 Series I, MS3112 Type Hermetic Square Flange Mount Receptacle with Bayonet Coupling and Solder Cup Termination
	237-240 MIL-DTL-26482 Series I Type Hermetic Special Square Flange Mount Receptacle with Bayonet Coupling and Solder Cup Termination
	257-135 MIL-DTL-26482 Series II Type Hermetic Bayonet Coupling Jam Nut Mount Pin-Pin Bulkhead Feedthrough Receptacle
	947-292 MIL-DTL-26482 Series II Type Hermetic Bayonet Coupling Jam Nut Mount Pin-Socket Bulkhead Feedthrough Receptacle
