Sav-Con® Connector Saver, MWDM2L

MWDM2L
Sav-Con® Connector Saver

These connector savers feature a one-piece aluminum housing, TwistPin contacts and locking hardware. Typical applications include test equipment and space-grade instruments. The Connector Saver prevents wear and tear on sensitive gear. Standard Connector Savers are electroless nickel plated. Other plating finishes are available on request.

  • Compact Size reduces stress on mating connectors.
  • In Stock, No Waiting – All standard Uni-Saver sizes are in stock (9, 15, 21, 25, 31, 37, 51, 75, 100 and 130 pin).
  • EMI Protected one piece shell.
Plug to Receptacle Sav-Con® Connector Saver MRM17109

MRM17109
Plug to Receptacle Sav-Con® Connector Saver

Sav-Con Connector Savers are the solution for mis-matched cables. Available for power only or power and signal combinations in 9 insert arrangements.

  • Mixed Signal and Power
177-007

177-007

Shorting Plug Assembly

Combining a switching backshell and a Micro-D connector, these assemblies have all contacts shorted to each other. These shorting plugs provide ESD protection to sensitive instrumentation.

Anti-Static Thermoplastic Dust Caps and Fluorosilicone Interfacial Seals

Anti-Static Thermoplastic Dust Caps and Fluorosilicone Interfacial Seals

  • Micro-D Plastic Dust Caps
    Always in stock,these anti-static black LDPE dust caps protect Micro-D connectors from debris and damage. All Glenair Micro-D connectors are furnished with these dust caps; however, these caps may be purchased separately for replacements.
  • Interfacial Seals
    Replace damaged Micro-D socket connector interfacial seals with new ones. Sometimes these seals can tear or be contaminated. Held in place by an interference fit with the contacts, damaged seals can be removed with tweezers.
500-017 and 500-037

500-017 and 500-037

Metal Protective Covers with Silicone Rubber Gaskets
These aluminum covers provide complete mechanical and environmental protection. A silicone gasket assures water-tight sealing. A variety of attachment styles are available.
500-107

500-107

Metal Protective Covers with Silicone Rubber Gaskets
780-555

780-555

"Marshall Bean" Protective Rubber Covers with Tether Rope
For protection of Micro-D's used in tactical equipment, these synthetic rubber covers are friction-fit and attach with nylon cord and ring terminals.
080-00-00-5XX

080-00-00-5XX

Stainless Steel Jackscrew Kits with E-Rings
179-013-XX

179-013-XX

Stainless Steel Jackscrew Kits with C Clips
080-00-00-1XX, 500-069-X-X, 177-504-X-X and 177-505-X-X-X

080-00-00-1XX, 500-069-X-X, 177-504-X-X and 177-505-X-X-X

Stainless Steel Jackpost Kits
Standard Hex, Rear Panel or Rear Panel PCB
