HiPer-D® M24308 Combo Power and Signal Connectors for Mission-Critical Applications

MIL-DTL-24308 Intermateable Advanced-Performance Crimp and PC Tail Environmental Connectors with #20 and #8 Contacts for Signal, Power and RF Applications

Combo D-subminiature M24308 connectors are ideally suited for use in analog signal, power, and RF applications. Glenair HiPer-D® connectors with combo layouts deliver both the flexibility and convenience of mixed size #8 and size #20 contact arrangements, as well as the high performance attributes of this ruggedized, environmental version of the M24308. Over 20 insert arrangements are available, including native size #8 as well as mixed size #8 and size #20. Crimp contact and PC board terminations are available with both standard and low profile shells. Designed for use in power controllers, radar systems, video applications and other military and aerospace electronic equipment. All HiPer-D® combo arrangements are tooled and ready for immediate application.

Reference and Technical Data

• Product Selection Guide
• Cutaway View
• Combo HiPer-D® Power, Signal and RF Contact Arrangements
• Combo HiPer-D® Materials and Finishes
• Combo HiPer-D® Product Specifications
